Model Specifications |
YSX050-A /YSX050-C |
|
Power |
5KW |
|
Voltage |
220V |
|
Power supply |
Single phase 220V/50HZ wire diameter>4mm2, internal resistance<0.5Ω |
|
mA |
32-100 mA |
|
mAs |
0.32--315mAs, stepping by R’10 |
|
KV |
40—110KV, stepping by 1KV |
|
Exposure time |
0.01~6.3s |
|
Focus |
0.6*0.6mm/1.8*1.8mm, dual focus |
|
Heat capacity |
42KHU |
|
Generator frequency |
30Khz |
|
Detector size |
14*17/17*17 inch |
|
Pixel |
140um |
|
A/D conversion |
16bits |
|
Spatial resolution |
3.6lp/mm |
|
Diagnostic software |
Profesional medical software |
|
Workstation |
Intel i5 processor, 8G memory, 128G SSD+1TB HDD, Monitor, WIN10/WIN7 |
