Medical AED Automatic External Defibrillator YSAED-300

Model: YSAED-300
  • ModelYSAED-300
  • BrandYSENMED
  • PriceGet Price
  • MOQ1
  • Ship FromFrom Guangzhou,China
  • ShippingAir/Sea
  • -
    +
    Categories:Defibrillators
    Share:
    Description Get Price Review
    Medical AED Automatic External Defibrillator

    Model:YSAED-300
    Defibrillator
    Category Specification
    Output Biphasic Truncated exponential
    Energy Sequence(child) 10J-100J(option)
    Energy Sequence(Adult) 100J-360J(option)
    Charge Time 4 sec.to 200J
    7 sec. to 360 J(New battery)
    Analysis Time 6 sec.
    The maximum time from the initiation of rhythm analysis to readiness for discharge with a new battery Less than 10 seconds
    The maximum time from the initiation of rhythm analysis to readiness for discharge after 6 shocks Less than 10 seconds
    The maximum time from initially switching power on to readiness for discharge Less than 15 seconds
    Visual Prompts LED prompts; Automatic Self-test
    Controls Three buttons: Defibrillation, mode switching, language switching
    Output Energy Accuracy ±10% into any impedance from 25Ω to 175Ω
    The Maximum Voltage 2000V±50V
    Output disabled when the patient impedance is outside limits 20Ω to 200Ω
    Battery
    Part No CR123A-4x3
    Non-rechargeable 4200mAh
    Capacity 200 times discharges at 360 Joules
    Shelf Life (25°C+15°C) 5 years standby (after installation)
    Physical
    Dimensions 280 x 209 x 80 mm
    Weight 2.6 kg
    Operating Temperature 0°C to 40°C
    Operating Humidity Relative humidity between 30% and 95%(non-condensing)
    Storage Temperature
    (without battery) -20°C to 55°C
    Storage Humidity
    (without battery) Up to 93%(non-condensing)
